Western Filters
Universal Mann+Hummel ProVent Catch Can Kit for Crankcase 12&16mm 1/2"-5/8" Hoses Nissan Patrol 2007-15 OS-PROV-10
Make 4x interest-free
payments of
$82.50 AUD
fortnightly
MORE INFO
Spend up to $1000.
Weekly, Fortnightly
or Monthly Repayments
MORE INFO
- SKU:
- OS-PROV-10
- UPC:
- 745110901105
- Condition:
- New
- Weight:
- 2.20 KGS
- Shipping:
- Calculated at Checkout
- fbt-product:
- /mann-hummel-replacement-element-lc-5001-2x-for-provent-200-iv-element-only/
Universal Mann+Hummel ProVent 12mm-16mm Oil Catch Can Kit suits:
Vehicles with a 12mm (1/2") & 16mm (5/8") Breather Hoses
With a 12mm Hose from the Crankcase and a 16mm Hose returning to the Air Intake.
Incl: Nissan Patrol 3.0L (from 2007-2015) CRD Common Rail Engines
Nissan Navara D22 3.0L ZD30 (2001-2005)
Genuine MANN+HUMMEL ProVent unit from Germany. Will stop sludge from collecting in your air intake & intercoolers !
Provent Kit Includes:
:: Provent Unit & Hoses
:: 4m Hose (12mm & 16mm)
:: Drain Kit :: Install Guide
Download PDF Installation Instructions >
Fitting Instructions:
Choose the best location to position the ProVent unit. If unsure, you'll find helpful information on the most 4wd forums.
Flow Direction - The Crankcase Outlet Hose is re-directed to the ProVent's Top Inlet. The Provent's Lower Outlet Hose is then connected to the Air intake.
(1) Work out where you are going to mount the ProVent in the Engine Bay.
(2) Slide the Silicone Reducers on to the inlet & outlet ports of the ProVent Unit.
(3) Decide whether to use the straight or elbow joiners to suit the unit’s engine bay location.
(4) Cut the 12mm and 16mm hoses to the required length and position sliders onto joiners.
Drain Kit: Attach to lower outlet of the ProVent unit and secure with clamp provided (ensure drain cock is in the CLOSED position – *drain periodically).
Cut clear hose to desired length.
Servicing: The ProVent 200 element will need replacing after between 30-40k kms or when oil starts to seep from the top cap & the ProVent body.
Note: The 12mm hose is used on the dirty side from the top of the crank case & the 16mm hose is the return side from the ProVent back into the air intake !
Mann+Hummel ProVent 200 Fitting Accessories >
To purchase a replacement MANN Oil Filter follow this link >
Please Note: We are based in Australia.
For International Customers, please email us for a Freight Quote.
Online Sales: jason@westernfilters.com.au
If unsure of the part's Vehicle Application & Fitment:
Find Your 'Vehicle' using our Parts Finder / REGO Search Widget
Click this LINK: Find My Vehicle/ REGO Search
-
Catch can for ZD30 CRD
Perfect fitment and fast delivery, all items as described and easy to install
-
Prevent catch can
In all honesty I reckon it is a great product it’s just a shame that I can’t get it to fit in my engine bay with out getting hoses made up, I don’t understand why the have to use a reduced hose I reckon there should just be a fitting to go directly onto the filter.
-
Provent 20
Great product out of the well packaged box, everything you need including instructions. Fitted the can to my 3.0 crd patrol before I finished my beer. And thanks for the lollipop.
