Universal Mann+Hummel ProVent Catch Can Kit for Crankcase 12mm (1/2") Outlet Nissan Patrol 3.0L ZD30 OS-PROV-09
Make 4x interest-free
payments of
$82.50 AUD
fortnightly
MORE INFO
Spend up to $1000.
Weekly, Fortnightly
or Monthly Repayments
MORE INFO
- SKU:
- OS-PROV-09
- UPC:
- 745110901099
- Condition:
- New
- Weight:
- 2.00 KGS
- Shipping:
- Calculated at Checkout
- fbt-product:
- /mann-hummel-replacement-element-lc-5001-2x-for-provent-200-iv-element-only/
Universal Mann+Hummel ProVent 12mm (1/2") Oil Catch Can Kit suits:
Vehicles with a 12mm (1/2") Crankcase Outlet
Incl. Nissan Patrol 3.0L DI (04/2000-08/2007) **Non Common Rail Engines**
The Half Inch Installation Kit is generally to suit the Nissan Patrol's & Navara's with the 3.0L ZD30 engines or any other engine with a Half Inch or 12mm fitting out of the top of the crankcase. Kit Includes a ProVent unit and hoses clamps and fittings. Genuine MANN+HUMMEL ProVent unit from Germany. Will stop sludge from collecting in your air intake & intercoolers ! Flow Direction: The Crankcase air is to come from the 'Outlet of the Crankcase' to the 'Top Inlet of the ProVent 200' with the 'ProVent's Lower Outlet' attached to the 'Engine's Air intake'.
Provent Kit Includes: :: Provent Unit & Hoses :: 12mm x 4m Hose :: Drain Kit :: Install Guide
Fitting Instructions:
Firstly choose the position you wish to mount the ProVent 200 unit (there are alot of good information on various 4WD online forums).
(1) Work out where you are going to mount the ProVent in the Engine Bay.
(2) Slide the Silicone Reducers on to the inlet & outlet ports of the ProVent Unit.
(3) Decide whether to use the straight or elbow joiners to suit where in the engine the unit is to be fitted.
(4) Cut the 12mm hose to suit length required & slider onto joiners.
Fitting Drain Kit (included):
Cut the clear hose to the desired length. Attach to lower outlet of the ProVent unit & secure with clamp provided. (Ensure Drain Tap is in closed position and drain periodically.
Servicing: The ProVent 200 element will need replacing between 30-40k kms or when oil starts to seep from the top cap & the ProVent body.
Download PDF Installation Instructions >
Purchase a replacement MANN Oil Filter follow this link >
Mann+Hummel ProVent 200 Fitting Accessories >
Please Note: We are based in Australia.
For International Customers, please email us for a Freight Quote.
Online Sales: jason@westernfilters.com.au
If unsure of the part's Vehicle Application & Fitment:
Find Your 'Vehicle' using our Parts Finder / REGO Search Widget
Click this LINK: Find My Vehicle/ REGO Search
-
Catch can
So easy to install
-
Check your intake hose size.
My Patrol is a 2004. it should have been a 12mm - 12mm but its actually a 16mm on the intake size. This didn't fit my 2004 ZD30DI patrol. $40 extra to order the required parts to make it fit. And I broke off the barb trying to get a 12mm hose on a 16mm fitting, not the kits fault, but so bloody annoying $100 replacement. So confirm the sizing yourself
-
Universal provent catch can for nissan patrol
Extremely fast delivery, easy installation and works a treat!
Thanks
