Toyota Hilux N70 2013-15 3.0L D4D KUN16-26 ABS Vehicle Specific Mann+Hummel ProVent Oil Catch Can Kit OS-PROV-01
Make 4x interest-free
payments of
$88.00 AUD
fortnightly
MORE INFO
Spend up to $1000.
Weekly, Fortnightly
or Monthly Repayments
MORE INFO
- SKU:
- OS-PROV-01
- UPC:
- 745110901006
- Condition:
- New
- Weight:
- 1.70 KGS
- Shipping:
- Calculated at Checkout
- fbt-product:
- /mann-hummel-replacement-element-lc-5001-2x-for-provent-200-iv-element-only/
ProVent 200 Oil Catch Can Kit suits: Toyota Hilux 3.0L 2013-2015
Turbo Diesel D4D KUN16 KUN26 (Autos and manuals)
** All of our kits are made to suit RIGHT-HAND DRIVE vehicles
they may suit some left hand drive vehicles but we cannot confirm **
** MUST HAVE ABS or VSC !
** For Hilux models without ABS (please see OS-PROV-34) **
Toyota Hilux D4D engines are well known for the problems they have with dirty EGR valves and other engine internals, to make sure this kit will suit your vehicle PLEASE check that there is a 140mm gap from the brake master cylinder to the air cleaner housing on the drivers side. This kit comes with very clear instructions and all of the components you will need to do the job. All hoses supplied with this kit are oil resistant and are of the highest quality, the mounting bracket is stainless steel and oil drain kit with brass ball valve.
Provent Kit OS-PROV-01 Includes:
:: Provent Unit
:: Stainless Steel Bracket
:: Top & Bottom Hoses
:: Drain Kit
Advantages of MANN+HUMMEL over cheaper imports:
• Highly efficient oil separation providing ideal protection for the turbo charger and other components installed downstream • Low pressure loss • less motor oil consumption in comparison to less efficient separators or conventional open systems • Maintenance friendly: fittings are not removed during Element maintenance • Universal usage: exceptional for variable Flow rates • Compact design • Light and robust design • integrated safety feature against irregularly high crankcase pressure • No electrical energy required • Low running costs.
Download PDF Installation Instructions >
Click to view individual replacement parts.
Mann+Hummel ProVent 200 Fitting Accessories >
Please Note: We are based in Australia.
For International Customers, please email us for a Freight Quote.
Online Sales: jason@westernfilters.com.au
If unsure of the part's Vehicle Application & Fitment:
Find Your 'Vehicle' using our Parts Finder / REGO Search Widget
Click this LINK: Find My Vehicle/ REGO Search
-
Toyota Hilux N70 2013-2015 provent 200 catch can filter
The filter and associated custom brackets was superior in quality and a pleasure to install. Fitted perfectly.
-
Great fit and easy to install
Postage was fast. Item fit awsome install was easy with good instructions
-
Great product, but kit not great
Great catch can, but unfortunately the custom kit for the hilux is not great. I expected more from a custom kit.
Hoses supplied rub in several places and the standard kit has one less small hose clamp than needed for drain. Quick nuts installed on bracket, but loose nuts supplied as well that are not required. Elbow on drain is not required and actually creates a rub point on fender under the catch can (removed and used clamp elsewhere, so had enough in the end) . Instructions need updating to match latest kit.
Install was easy.
I'm a mechanical engineer.
